3014 SMD LED
3014 SMD LEDs - Hongcheng Optoelectronics LED Manufacturer
Product Overview:
3014 is a compact top-emitting SMD LED with a 3.0×1.4mm package. It offers small size, high brightness, low power consumption, uniform emission and good stability. Suitable for backlight modules, light strips, luminaires and electronic equipment indicator light sources. Color, brightness, voltage, color temperature and wavelength can be customized.
Key Advantages:
- Compact 3014 package saves PCB mounting space
- Top emission, high brightness and uniform light color
- Low power consumption and low heat for dense arrays
- Available in white, warm white, red, green, blue and other colors
- Brightness, color temperature, wavelength and voltage binning available
- Suitable for automated SMD production and reflow soldering
Applications:
- LED flexible strips, light bars and linear lighting
- LCD backlighting, panel backlighting and light-guide modules
- Home appliance panels, instruments and electronic equipment
- Advertising signage, decorative lighting and landscape illumination
- Vehicle interior lights and auxiliary indicator light sources
Product Features:
Chip: Grade A chips from leading brands in Taiwan and mainland China provide high brightness, low light degradation, stable output and strong ESD resistance.
Gold wire: 99.99% pure gold wire bonding provides good conductivity and stable, reliable bonds.
Encapsulant: high-quality material resists sulfurization, high temperatures and lumen depreciation, improving emission consistency.
Lead frame: A highly thermally conductive lead frame provides good heat dissipation, easy solder wetting and oxidation resistance.
Packaging: Vacuum moisture-resistant tape packaging, with reel shipment available for automated SMD production.
Category: 3014 SMD LEDs
Quick Reference: Key Optoelectronic Parameters (by Emission Color)
Test conditions: See the IF column for test current; ambient temperature 25℃. Data is taken from each model's datasheet. “—” indicates that the datasheet does not specify this item. Download the corresponding PDF for complete specifications.
| Emission Color | Part Number | Forward Voltage VF (V) | Wavelength / Color Temperature CCT | Optical Output (see values/notes for units) | Viewing Angle 2θ½ (°) | Test Current IF (mA) | Operating Temperature |
|---|---|---|---|---|---|---|---|
| Warm White | HC-3014TW4C-AHL-1 | 2.8~3.4 | 2700~3000 K | 10~12 lm | 120 | 30 | -20 ~ +80℃ |
| White | HC-3014TWC-AL-15 | 2.8~3.4 | 6000~7000 K | 10~12 lm | 120 | 30 | -20 ~ +80℃ |
| Red | HC-3014TR3C-AL-2 | 1.8~2.4 | 620~630 nm | 400~800 mcd | 120 | 30 | -40 ~ +80℃ |
| Blue | HC-3014TBC-XS | 2.8~3.4 | 460~465 nm | 700~1000 mcd | 120 | 30 | -40 ~ +80℃ |
| Orange | HC-3014TO2C-B4 | 1.8~2.4 | 600~610 nm | 500~1000 mcd | 120 | 30 | -40 ~ +80℃ |
Related Products
3014 SMD LED An SMD indicator LED with a forward voltage of 1.8~3.4V (depending on emission color) and a drive current in the 20mA range. Supports fully automatic SMT assembly and reflow soldering. Factory-direct from Dongguan Hongcheng Optoelectronics Co., Ltd. (an international member of Guangyu Group with over 20 years of LED packaging experience), it uses Grade A chips and 99.99% pure gold wire bonding and is RoHS certified. Free samples and custom brightness binning, color-temperature binning and tape packaging are available. Download the datasheet PDF on this page for complete electrical parameters and mounting dimensions.
Q: Can mid-power LEDs such as 2835/3014 be connected directly to 220V?
A: No. These LEDs are low-voltage 2-3.4V devices and require a constant-current driver supply. We can provide driver matching advice and support for complete luminaire solutions.
Product Specifications at a Glance
| Product Name | 3014 SMD LED |
|---|---|
| Package: | SMD package |
| Dimensions | 3.0×1.4mm |
| Mounting: | SMD surface mounting (suitable for reflow soldering) |
| Emission Color | Single-color options available |
| Environmental Certification | RoHS |
| Packaging Quantity | 2,000 pcs/reel (taped) |
| Manufacturer | Dongguan Hongcheng Optoelectronics Co., Ltd. |
| Customization: | Custom colors, brightness and wavelength binning, and encapsulants available; confirm details when requesting a quote |
| Detailed Specifications | See the datasheet PDF on this page for complete electrical parameters |
| Minimum Order Quantity (MOQ) | 2K (2,000 pcs, 1 tape-and-reel) |
| Sample Lead Time | Typically 3-4 working days |
| Volume Production Lead Time | Typically 10-15 working days |
💡 Typical Applications: Common applications include LED strips, light bars and linear lighting, LCD backlighting, panel backlighting and light guide modules, home appliance panels, instruments and electronic equipment, advertising signage, decorative lighting and landscape illumination.
Forward Voltage and Wavelength Quick Reference by Color
Voltage varies significantly between colors in the same package. Select current-limiting resistors using the values for the specific color:
| Emission Color | Wavelength Range | Forward Voltage | Chip Material |
|---|---|---|---|
| Red | 620~625nm | 1.8~2.4V | AlGaInP |
| Yellow | 585~595nm | 1.8~2.4V | AlGaInP |
| Orange | 600~610nm | 1.8~2.4V | AlGaInP |
| Standard Green | 565~575nm | 1.8~2.4V | AlGaInP |
| Emerald Green | 520~530nm | 2.8~3.4V | InGaN |
| Blue | 450~470nm | 2.8~3.4V | InGaN |
| White (Neutral White) | Full Spectrum | 3.0~3.4V | InGaN + phosphor |
Ordering and Inquiry Information
Packaging quantity refers to taped packaging (2,000 pcs per reel); minimum order quantity: 2K (2,000 pcs, orders start at one full taped reel). Sample lead time is generally 3-4 working days, and volume production lead time is generally 10-15 working days (subject to order confirmation). For volume pricing, use the inquiry form on this page or call/message us on WeChat at 139 2571 4318. Specify the exact model and quantity in your inquiry.
Selection Recommendations
Forward voltage varies considerably by color/model (commonly 1.8~3.4V). Calculate current-limiting resistors using the VF range in the selected model's datasheet, and set the reflow profile according to the corresponding datasheet.
