Patch 3528
Product Features:
Chip: Professional LED - energy-saving A-level chip with long lifespan, long-lasting light effect, and stable output.
Gold wire: Welding with 99.9% pure gold wire, fast heat dissipation, good conductivity, and good stability.
Glue: High quality glue is used to provide dual protection against vulcanization and pressure; High refractive index, exciting the highest brightness.
Bracket: Silver plated moisture-proof bracket with good thermal conductivity, easy to tin and not easily oxidized.
Product specification sheet Click to download
Product specification sheet Click to download
Product specification sheet Click to download
Product specification sheet Click to download
Product specification sheet Click to download
Product specification sheet Click to download
Product specification sheet Click to download
Product specification sheet Click to download
Product specification sheet Click to download
Product specification sheet Click to download
| luminescent color | material | beam angle | Forward voltage | luminance （@20mA） |
Color temperature/wavelength (nm) | |||
| Trp | Max | Min | Max | Min | Max | |||
| RED | AlGalnP | 120° | 1.8 | 2.4 | 100 | 500 | 620 | 630 |
| Pure Green | InGaN | 120° | 2.8 | 3.4 | 300 | 700 | 520 | 530 |
| Blue | InGaN | 120° | 2.8 | 3.4 | 300 | 700 | 460 | 470 |
| Wanw White | InGaN | 120° | 2.8 | 3.4 | 2500 | 3200 | 3000K | 3000K |
| White | InGaN | 120° | 2.8 | 3.4 | 2800 | 3500 | 6500K | 6500K |
| RED | AlGalnP | 120° | 1.8 | 2.4 | 500 | 1000 | 620 | 625 |
| Pure Green | InGaN | 120° | 2.8 | 3.4 | 400 | 1200 | 520 | 530 |
| Blue | InGaN | 120° | 2.8 | 3.4 | 300 | 800 | 460 | 470 |
